| Quantity: | |
|---|---|
Heat shrinkable tube is widely used for insulation or protecting of wire harness, strain relief of wire terminations and connections, bundling of wire harness, protection of soldered points, insulation and capsule of electronic components, anti-corrosive protection, identification and Color coding.
| Product Name | Dual Wall Adhesive 1 KV water proof Heat Shrink Tube | ||
| Size | 8mm | ||
| Material | PE | ||
| Shrinkage ratio | 3:1 (will maximum shrink to 1/3 of its supplied diameter) | ||
| Minimum shrinkage temp | ≥84°C | ||
| Full shrinkage temp | ≥120°C | ||
| Operating temperature | -55°C to +125°C | ||
| Tensile strength | 10.4 Mpa | ||
| Dielectric strength | 1KV | ||
| Manufacture specification | ISO9001 | ||
| Flammability | Flame retardant | ||
| Part No. | size | width | standard packaging | Part No. | size | width | standard packaging |
| (mm) | (mm) | m/roll | (mm) | (mm) | m/roll | ||
| Φ1 | 1.5±0.2 | / | 200 | Φ16 | 16.5±0.5 | 26.8 | 100 |
| Φ1.5 | 2.0±0.2 | / | 200 | Φ18 | 19.0±0.5 | 29.7 | 100 |
| Φ2 | 2.5±0.2 | / | 200 | Φ20 | 21.0±0.5 | 33.5 | 100 |
| Φ2.5 | 3.0±0.2 | / | 200 | Φ22 | 23.0±0.5 | 35.5 | 100 |
| Φ3 | 3.5±0.3 | / | 200 | Φ25 | 26.0±0.5 | 41 | 25 |
| Φ3.5 | 4.0±0.3 | / | 200 | Φ30 | 31.5±1.0 | 48.7 | 25 |
| Φ4 | 4.5±0.3 | / | 200 | Φ35 | 36.5±1.0 | 56.3 | 25 |
| Φ5 | 5.5±0.4 | / | 100 | Φ40 | 41.5±1.0 | 65 | 25 |
| Φ6 | 6.5±0.4 | / | 100 | Φ50 | ≥50 | 81.3 | 25 |
| Φ7 | 7.5±0.4 | 10.3 | 100 | Φ60 | ≥60 | 95.2 | 25 |
| Φ8 | 8.5±0.5 | 13.7 | 100 | Φ70 | ≥70 | 111.7 | 25 |
| Φ9 | 9.5±0.5 | 14.8 | 100 | Φ80 | ≥80 | 126.1 | 25 |
| Φ10 | 10.5±0.5 | 17.3 | 100 | Φ90 | ≥90 | 140.5 | 25 |
| Φ12 | 12.5±0.5 | 20.0 | 100 | Φ100 | ≥100 | 157.1 | 25 |
| Φ14 | 14.5±0.5 | 23.3 | 100 | Φ120 | ≥120 | 185 | 25 |
| Φ15 | 15.5±0.5 | 25.0 | 100 | Φ150 | ≥150 | 220 | 25 |
Hebei Parlmu Rubber & Plastic Products Co., Ltd. is a professional manufacturer engaged in the research, development, production, sale, and service of spiral Hose Guard, Rubber Hose, Rubber Gasket, Sealing Strip and other rubber products. We are located in Hebei with convenient transportation access. Dedicated to strict quality control and thoughtful customer service, our experienced staff members are always available to discuss your requirements and ensure full customer satisfaction. In recent years, our company has introduced a series of advanced equipment. In addition, we have obtained Rosh and SGS certificates.
Q1: Are you a factory?
A1: We are the manufacturer, 30 years experiences in this field.
Q2: How long is the delivery time?
A2: It depends on the quantity. For samples or regular items in small qty, we promise to send in 1-3 days. Most have in stock. For mass production, about 7-20 days.
03: How about the payment terms?
A3: We accept L/C, west union and T/T.
Q4: Which shipping method do you provide?
A4: For samples or small orders, goods will be sent by express. For regular orders, goods can be sent by air or by sea, just according to your demand.
Q5: How can we get the samples? Do I need to pay?
A5: We provide giveaway samples by express, but you need to pay the express charge.
Q6: What's the price?
A6: Different items different market will be different cost, we will keep to give best and competitive price for each customer.
Q7: How do we know you are a reliable supplier?
A7: Parlmu is a manufacturer for more than 30 years of Specializing in various of the rubber product. welcome to our factory.
